BENCHTOP LCR METER
100Hz ~ 10KHz
TLLCR-1001
TEKLAB introduced Benchtop LCR Meter measures inductance, capacitance, and resistance and has wide range, frequency flexibility, advanced functions, and durable design.
FEATURES
- LARGE 3.5” Colour LCD display, Adjustable Backlight
- Multi Freq. Range: 100Hz ~ 10 K Hz in 10 Steps
- Fast Measurement Speed: 10Times per Second
- Handler interface for automatic sorting
- Support DC Resistance & Electrolytic Capacitance Measurement
- RS232&USB. Supports SCPI Communication protocol.
- 5Digits Display-Both Primary & Secondary
- Automatic identification of component type
- High Stability, Auto/Locked Range
- Data Recording Function
